Maintenance truck-Dongfeng -2022.05.11-V1.2 EURO 4
Classification:
Contact：
Detail
| FOB SHANGHAI | 33100USD | DELIVERY TIME | 1MONTH | |
| NO. | Maintenance truck configuration | configuration name | configuration details | A |
| 1 | truck chassis | Dongfeng Duolika Single row | 3308mm wheelbase，LHD，Yuchai Brand diesel engine 85KW 300N.m Euro 4, Manual-5 Forwarder gearbox, Power steering,air brake, ABS, 7.00R16 6+1pcs tire, A/C, 100An bettery. 80L oil tank. | 1 |
| 2 | Van | van details | L*W*H 4200x2200X1800mm.With a rack, various functional modules installation base, hand washing device, waste collection box, storage rack, etc | 1 |
| 3 | power cabin | (380V power supply 12bar air supply | 13 hp Honda generator, electric start, imported Italy 5.5KW air compressor, European version 5KW generator | 1 |
| 4 | waste oil collect system | waste oil collect system（700L） | 700L built-in oil and gas separator waste oil tank, European type vacuum pump, imported 1 inch Sharp technology heavy industrial coil, vacuum waste oil collector, etc | 1 |
| 5 | Hydraulic oil filling ssystem | Hydraulic oil filling system | FAMOUS brand gear pump, imported 1 inch sharp technology heavy industrial coil, etc | 1 |
| 6 | Gear oil filling system | Portable gear oil filling device | 220V portable electric gear oil filling pump | 1 |
| 7 | The lubrication system flushes the filtration system | The lubrication system flushes the filtration system | With imported pneumatic diaphragm pump flushing filtration system | 1 |
| 8 | Waste filter collection system | Waste filter collection system | Stainless steel with filter screen and filter socket 30L waste filter collector | 1 |
| 9 | Elec-control system | Buttons and remote control | Button plus remote control, overpressure automatic stop protection, waste oil level monitoring protection, etc | 1 |
| 10 | Compress air supply system | compress air supply system | Sharp technology coil, air distribution system, etc | 1 |
| 11 | power supply system | power supply system | American Sharp wire coil 220V 15m | 1 |
| 12 | Tool collect | tool box | Vehicle tool cabinet | 1 |
| heavy duty tool box | Vehicle tool cabinet | 1 | ||
| 13 | light system | working light | Luminous LED square light, charging work light super bright, a portable LED, a multi-functional light with strong magnetic | 1 |
| 14 | vehicle's crane system | 200-400KG Electric hoist | Pneumatic legs, seamless steel tube davit, PA400 electric hoist, 270 degrees rotation Angle (90 degrees on the car, 180 degrees off the car) | NO Fit cost -410USD |
| 15 | Basic purpose | Suitable for factory, engineering machinery, commercial vehicles, passenger car, the scene of agricultural machinery repair, maintenance, hydraulic oil filling quantitative filling, supplying oil, gear oil, grease filling (butter), tire repair, emergency start, etc., and can satisfy the customer equipment to the strict requirement of the lubricating oil cleanliness, and at the same time to provide customers the lubrication system of washing services. | ||
| 16 | vehicle overall size: | 6000x2250x3000mm | ||
